0 specifications, Electrical specifications, Physical specifications – ETS-Lindgren 7604 Shielded Coil Antenna User Manual
Page 11
3.0 Specifications
Electrical Specifications
Useful Frequency Range:
20 Hz to >500 kHz
Connector:
BNC receptacle
Coil
Winding:
36 turns of 7-41 Litz wire
electromagnetically shielded
Resistance:
10 Ohms, nominal
Inductance:
340 µH, nominal
Physical Specifications
Coil Diameter:
133 mm (5.24 in)
Weight:
0.91 kg (2 lb)
Specifications
| 11
