5.0 Model 3305 Suggested Test Setup
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
Measuring Electronic Field Shielding Effectiveness
Reduce amplifier power to zero watts before
band switching the Model 3303.
Reference:
• NSA 65-6
• MIL-STD-285
1. Place the transmitting and receiving antennas so that they are
24 inches plus the thickness of the screen room wall apart from each
other.
2. Set up equipment as shown in Suggested Test Setup Diagram on
page 22.
3. Turn generator to ON position.
Disable RF output of generator.
Turn amplifier to ON position.
Turn receiver to ON position.
Turn Model 3301C power on.
Set receiver.
Set the attenuator at maximum (100 dB–150 dB) attenuation.
Enable RF output of the generator.
4. Adjust signal amplitude on signal generator to maximum allowed by
amplifier input.
Model 3305 Suggested Test Setup | 21
