Specifications | 15
3.0 Specifications
Electrical Specifications
3162-01 3162-02
Frequency Range: 1.1 GHz –1.5 GHz 2.7 GHz –3.1 GHz
Input Impedance: 50 Ω 50 Ω
VSWR: 1.5:1 Typical
2:1 Maximum
1.5:1 Typical
2:1 Maximum
Maximum Continuous
Input Power:
550 W 500 W
RF Connector: Type N female Type N female
Physical Specifications
3162-01 3162-02
Length: 160.27 cm
63.1 in
79.2 cm
31.2 in
Width: 64.77 cm
25.5 in
44.2 cm
17.4 in
Height: 74.68 cm
29.4 in
58.4 cm
23.0 in
Weight: 23.6 kg
52.0 lb
10.0 kg
22.0 lb
