14 | Mounting Instructions
Mounting the Biconical Elements
1. Once the balun
unit is securely
connected to the
boom, align the
threads on one
of the biconical
elements with
the receptacle on
the end of the
balun, and then
turn the biconical
element until it is
firmly seated in
the balun.
2. Tighten bolt to secure element.
3. Repeat steps for the remaining biconical element.
4. Once both elements are connected, attach the input cable to the connector
on the bottom of the balun.
