Specifications | 11
3.0 Specifications
Electrical Specifications
Frequency: 30 MHz–100 MHz
Input Impedance: 50 Ω
VSWR: • Typical—2:1
• Maximum—4:1
Maximum RF Input Power: 10 kW
RF Connector: 1 5/8 in EIA flange
Physical Specifications
M ODEL 3159 A NTENNA
Length: 3 m (9.8 ft)
Diameter: 1.04 m (3.4 ft)
M ODEL 3159 P EDESTAL
Length: 232.4 cm (91.5 in)
Width: 160 cm (63 in)
Total Height With Antenna: 365.7 cm (144 in)
Air Pressure Required: 80–120 PSI
