ETS-Lindgren 3147 Log Periodic Dipole Array Antenna - Manual (Page 38)

40 W ATTS C ONTINUOUS P OWER
Field Strength (E)
Freq
(MHz)
AF
Gain
(dB)
Gain
(num)
1 V/m 10 V/m 20 V/m
1000 23.2 7.0 5.0 0.060 6.0 23.9
1100 23.4 7.6 5.8 0.052 5.2 20.8
1200 23.8 8.1 6.5 0.046 4.6 18.6
1300 24.1 8.4 6.9 0.043 4.3 17.3
1400 25.6 7.5 5.6 0.053 5.3 21.3
1500 26.2 7.6 5.8 0.052 5.2 20.8
1600 26.7 7.6 5.8 0.052 5.2 20.8
1700 27.6 7.3 5.4 0.056 5.6 22.3
1800 28.5 6.9 4.9 0.061 6.1 24.5
1900 28.5 7.3 5.4 0.056 5.6 22.3
2000 29.1 7.2 5.2 0.057 5.7 22.9
2100 29.8 6.9 4.9 0.061 6.1 24.5
2200 30.0 7.1 5.1 0.058 5.8 23.4
2300 30.5 7.0 5.0 0.060 6.0 23.9
2400 31.4 6.5 4.5 0.067 6.7 26.9
2500 32.2 6.0 4.0 0.075 7.5 30.1
2600 32.8 5.7 3.7 0.081 8.0 32.3
2700 33.8 5.0 3.2 0.095 9.5 37.9
2800 32.7 6.5 4.5 0.067 6.7 26.9
2900 33.4 6.1 4.1 0.074 7.4 29.4
38 | Power Requirements
