Specifications | 13
3.0 Specifications
Electrical Specifications
Frequency Range: 100 MHz – 1.1 GHz
Input Impedance: 50 Ω
VSWR: • Average – 1.5:1
• Maximum – 3.5:1 *
* At the extremes of the operational band.
CW Power: 1000 W
Connectors: Type N female (2)
Physical Specifications
Antenna
Height: 1325.6 mm
52.19 in
Width: 1621.8 mm
63.85 in
Weight: 40.144 lb
18.2 kg
Base
Dimensions: 254.0 mm x 254.0 mm
10.0 in x 10.0 in
