9 Introduction www.ets-lindgren.com
Standard Configuration
Note: All Model 3126 dipole antennas are not listed in this manual;
contact ETS-Lindgren Sales for a list of available Model 3126 dipole
antennas.
 Model 3126 Sleeve Dipole Antenna
 A2LA accredited precision calibration and symmetry certification
including signed Certificate of Calibration
Optional Items
Note: Contact ETS-Lindgren Sales for information on ordering
optional items.
CTIA R IPPLE T EST M OUNTING K IT
This optional ripple test mounting kit is available to attach the dipole to an
ETS-Lindgren Multi-Axis Positioning System (MAPS™). The mounting kit
provides the adapters necessary to position dipole and loop antennas at each
offset geometry required to perform the ripple test, as specified in the CTIA test
plan. The center position mount can also be used for performing range
calibrations (CTIA Substitution Part) and is the same mount design used for
calibrating the antenna, thereby reducing measurement uncertainty.
M ODEL 3127 R ESONANT L OOP A NTENNA
Magnetic dipole antennas designed to meet the CTIA +\-0.1 dB symmetry
requirement for ripple test measurements at the labeled center frequency.
