14 Specifications www.ets-lindgren.com
Band % Band
1.2:1
VSWR
% Band
2:1
VSWR
Calibration
Range (MHz)
Centered at f 0
Minimum
Gain
at f 0 (dB)
Pass / Fail Criteria
836MHz —1000MHz 2.5% 15% 200 MHz 1.5  1.2:1 VSWR on a 2.5% band centered
at f 0
 Symmetry <0.2 dB for 2:1 VSWR band
 Meet minimum gain at f
0
1000MHz —1800MHz 3% 15% 300 MHz 1.5  1.2:1 VSWR on a 3% band centered
at f 0
 Symmetry <0.2 dB for 2:1 VSWR band
 Meet minimum gain at f 0
1800 MHz —1920 MHz 3% 15% 300 MHz 1.5  1.2:1 VSWR on a 3% band centered
at f 0
 Symmetry <0.2 dB for 2:1 VSWR band
 Meet minimum gain at f 0
1920 MHz —2150 MHz 4% 15% 20% of band 1.5  1.2:1 VSWR on a 4% band centered
at f
0
 Symmetry <0. 2dB for 2:1 VSWR band
 Meet minimum gain at f
0
