Mounting Instructions | 17
5.0 Mounting Instructions
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
The Model 3110C is a precision measurement
device. Handle with care.
Using Included Mounting Adapters
The Model 3110C Biconical Antenna ships with these mounting adapters:
 102108 Clamp Block —Uses standard
7/8 –14 threads and comes with a 1/4–20
thread adapter for mounting to an
ETS-Lindgren tripod or most other
tripods.
 101942B Support Base
 100733 Support Rod
