3.0 Specifications

Electrical Specifications

Frequency Range:

10 kHz–30 MHz

• Band 1: 10 kHz–5 MHz

• Band 2: 5 MHz–30 MHz

Input Impedance:

50 Ohms

Field Pattern:

At one meter on centerline the field

is a linearly polarized, essentially

homogenous E-field.

E-Field Capability:

See tables on page 14 and page 16.

Maximum Power Capability:

1000 Watts

Connector:

Type N

Physical Specifications (Assembled)

Length:

184.15 cm (72.5 in)

Width (Element Separation):

60.96 cm (24.0 in)

Height:

5.08 cm (2.0 in)

Weight:

5.44 kg (12.0 lb)

Specifications

| 13
