S402/403 application, Application by system – EFCO 403 Series Roto Vent for Storefront User Manual

Page 5

background image

9221

WEEP

Screw spline
is similar.

S402/403 APPLICATION

Shear block
attachment shown.

SECTION III -

APPLICATION BY SYSTEM

PAGE 4

S100

S100

S100

S100

STK0

STD3

STT7

9959

9314

H190

(9955)

K159

(9955)

K159

9952

9229

9229

9953

8 7/16" SIGHTLINE

1 3/16"
