EFCO Duracast Pressure Plate User Manual
Page 5
EFCO CORPORATION 6/2012 PART NO. YW45
5
Duracast Pressure Plate Installation Instructions
5600 Series — Outside Glazed Installation
A. Seal and install Joint plugs per Installation Instruction
Y302 - Section VI: Glazing
Preparation
. DO NOT install a Thermal Isolator as indicated in Steps 1A and 1B.
B.
Install Setting Blocks, Infill Glazing Material, Temporary Retainers, and Side Blocks per
Installation Instruction
Y302 - Section VII: Glazing Installation, Steps #3 thru #5.
5900 Series — Outside Glazed Installation
A. Seal and install Joint plugs per Installation Instruction
Y350 - Sections VI: Joint Plug Appli-
cation.
B. Install Glazing Adaptors / Mullion Gaskets per Installation Instruction
Y350 - Sections VII:
Glazing Adaptors / Mullion Gaskets.
C.
Install Setting Blocks, Infill Glazing Material, and Anti-Walk Blocks ONLY per Installation
Instruction
Y350 - Sections VIII: Setting Blocks / Anti-Walk Blocks / Pressure Plate
Gaskets
. Follow the instructions in this document for the installation of the Pressure
Plate. See
Section III - Pressure Plate Installation
Section II: Glazing Prep. & Installation
Note: All anchors must be “FIXED” before glazing installation begins.
