Rotary Switch Control Head, Parts List
Ref No. Description Part No. Qty.
1 Flat Washer, 3/8" x .020" T00667 1
2 Nut, 3/8" -32 x 1/2" x .090" T01082 1
3 Switch Assembly w/Harness S55229 1
4 Knob, Rectangular T01917 1
5 Knob, Selector T03537 1
6 Insert, Selector Knob T03538 1
7 4 - 40 x 3/8", Pan Hd Phil, Black Oxide T06937 8
8 Switch Actuator Keypad, 1x6, Silicone Rubber T10878 1
9 Standoff, 4 - 40 x .75" T10890 2
10 Switch Actuator, Small Arc, RLS Sirens T10913 2
11 Switch Actuator, Large Arc, RLS Sirens T10914 2
12 Switch Actuator, Oval, RLS Sirens T10915 2
13 Enclosure, Control Head, RLS Siren T11207 1
14 Label, Faceplate, Model 3997R T11270 1
Label, Faceplate, Model 3998R T11268 1
Label, Faceplate, Model 3999R T11269 1
15 E-Tray, Control Head, RLS Sirens S71531 1
16 PCB Assembly, Control Head, 1
Model 3997R T11297
Model 3998R T11298
Model 3999R T11299
Not Shown:
1/4 - 20 x .375", Hex Washer Hd, Zinc T10912 2
Bracket, Control Head, RLS Sirens S71528 2
