Figure 1
WARNING!
!
Larger wires and tight connections will provide longer service life for components. For high
current wires it is highly recommended that terminal blocks or soldered connections be used
with shrink tubing to protect the connections. Do not use insulation displacement connectors
(e.g. 3M
® ) Scotchlock type connectors). Route wiring using grommets and sealant when
passing through compartment walls. Minimize the number of splices to reduce voltage drop.
High ambient temperatures (e.g. underhood) will significantly reduce the current carrying
capacity of wires, fuses, and circuit breakers. Use "SXL" type wire in engine compartment.
All wiring should conform to the minimum wire size and other recommendations of the
manufacturer and be protected from moving parts and hot surfaces. Looms, grommets, cable
ties, and similar installation hardware should be used to anchor and protect all wiring.
Fuses or circuit breakers should be located as close to the power takeoff points as possible
and properly sized to protect the wiring and devices. Particular attention should be paid to the
location and method of making electrical connections and splices to protect these points
from corrosion and loss of conductivity. Ground (Earth) terminations should only be made
to substantial chassis components, preferably directly to the vehicle battery.
The user should install a circuit breaker sized to approximately 125% of the maximum Amp
capacity in the supply line to protect against short circuits. For example, a 30 Amp circuit
breaker should carry a maximum of 24 Amps.
DO NOT USE 1/4" DIAMETER GLASS FUSES AS THEY ARE NOT SUITABLE FOR
CONTINUOUS DUTY IN SIZES ABOVE 15 AMPS. Circuit breakers are very sensitive to
high temperatures and will "false trip" when mounted in hot environments or operated close
to their capacity.
WARNING!
!
CONNECTION OF A 58 WATT SPEAKER TO THE SPKR TERMINAL WILL CAUSE THE
SPEAKER TO BURN OUT, AND WILL VOID THE SPEAKER WARRANTY!
The sound projecting opening should be pointed forward, parallel to the ground, and not
obstructed or muffled by structural components of the vehicle. Concealed or under-hood
mountings in some cases will result in a dramatic reduction in performance. To minimize this
reduction, mount the speaker so the sound emitted is projected directly forward and
obstruction by vehicle components such as hoses, brackets, grille, etc. is minimized.
Electromechanical sirens and electronic siren speakers should be mounted as far from the
occupants as possible using acoustically insulated compartments and isolation mountings to
minimize the transmission of sound into the vehicle. It may be helpful to mount the device on
the front bumper, engine cowl or fender; heavily insulate the passenger compartment; and
operate the siren only with the windows closed.
Each of these approaches may cause significant operational problems, including loss of siren
performance from road slush, increased likelihood of damage to the siren in minor collisions,
and the inability to hear the sirens on other emergency vehicles.
APPROPRIATE TRAINING OF VEHICLE OPERATORS IS RECOMMENDED TO ALERT
THEM TO THESE PROBLEMS AND MINIMIZE THE EFFECT OF THESE PROBLEMS
DURING OPERATIONS.
The bail is mounted to the siren chassis by means of the "T" slot in
the side of the unit and the 1/4-20 hex head bolts, washers, and
nuts supplied. See Figure 1 for assembly and positioning details.
Note that once the unit is installed, removal involves only
loosening, not removing, the acorn nuts.
NOTE: Set-ups and adjustments will be made in subsequent steps,
depending upon the model and options purchased, that may
require access to the rear area of the unit. Plan the installation and
wiring accordingly.
Connections (see Figure 2)
ORANGE - Speaker - Connect to 100W ( 11 ohm ) speaker leads.
