Bplus MP2A User Manual

Page 13

Mini PCI-E to PCI-E Adapter User’s Manual

Page 12

Attention:

1. Do not deal with it when energized, incorrect approach will

lead to product damage.

2. Accessories include ONE pcs USB cable line and ONE pcs

DuPont 5P to 5P cable line. They CANNOT be used at the

same time.

3. The support style of mini card decides the installation

position for MP2A. If your card supports PCI-E mode,

please plug MP2A into PCI-E slot. Or it supports USB mode,

then MP2A should be connected by cable line rather than

PCI-E slot connect.

PCI-E Mode
