AVer Vandal Dome IP cam(E) Installation Guide - Manual (Page 23)

21
ENGLISH
Model FV2028 (E)
Interface
Digital input/output 1/1
BNC Video output Yes
Built-in storage option Micro SDHC & SDXC card (64GB max.)
Built-in microphone N/A
External microphone input Yes
External Audio output Yes
General
Power supply DC 12V(2A)/PoE
Power consumption
PoE (TYP.):
7W (LED off)
14W (LED on)
DC-IN (TYP.):
5W (LED off)
13W (LED on)
PoE PoE Class 3 (IEEE802.3at)
Dimensions ψ144.3 x H114.4 (mm)
Net weight 1200g
3-axis bracket adjustment
angle
pan: 280°, tilt: 30°~90°, rotation: 100°
Temperature and humidity
-15°C~50°C, 20%~90% Cold Start
-25°C~50°C, 20%~90% Operating
IP Rating IP68
IK Rating IK10
