AVer Vandal Dome IP cam(E) Installation Guide - Manual (Page 2)

Table of Contents
IMPORTANT SAFEGUARD ................................................................................................. 1
PACKAGE CONTENTS ....................................................................................................... 2
OPTIONAL ACCESSORIES ................................................................................................ 2
IP CAMERA PARTS ............................................................................................................. 3
IP CAMERA INSTALLATION ............................................................................................... 4
D EPLOYING N ETWORK ........................................................................................................ 4
Network Connection via Ethernet Switch .................................................................... 4
Connect the power adapter to power jack of camera .................................................. 4
Power over Ethernet Connection ................................................................................ 5
C
ONNECTING
E
XTERNAL
D
EVICES TO
I/O T
ERMINAL
B
LOCK
.................................................... 6
I NTERNAL C ONNECTION D IAGRAM OF DI/DO ......................................................................... 6
M OUNTING THE IP C AMERA ................................................................................................. 7
F OCUSING THE IP C AMERA WITH BNC M ONITOR ................................................................... 8
I NSERTING MICRO SD C ARD TO S YSTEM ................................................................................ 9
RESETTING HARDWARE ................................................................................................. 10
TECHNICAL SPECIFICATIONS ........................................................................................ 11
FV2028-T (E)/FV2028-TM (E) ..................................................................... 11
FV3028-RT (E)/FV3028-RTM (E) ................................................................ 15
FV2028 (E) .................................................................................................... 19
FCC NOTICE (CLASS B) .................................................................................................. 23
NOTICE .............................................................................................................................. 23
WARNING .......................................................................................................................... 23
GOVERNING LAW AND YOUR RIGHTS .......................................................................... 25
