AVer Vandal Dome Installation Guide - Manual (Page 23)

21
ENGLISH
Model FV3028-RT FV3028-RTM
Interface
Digital input/output 1/1
BNC Video output Yes
Built-in storage option Micro SDHC & SDXC card (64GB max.)
Built-in microphone N/A
External microphone input Yes
External Audio output Yes
General
Power supply DC 12V(2A)/PoE
Power consumption
PoE (TYP.):
7W (LED/Heater off)
14W (LED on, Heater off)
15W (LED off, Heater on)
22W (LED/Heater on)
DC-IN (TYP.):
5W (LED/Heater off)
12W (LED on, Heater off)
13W (LED off, Heter on)
20W (LED/Hearer on)
PoE PoE Class 4 (IEEE802.3af)
Dimensions
ψ 144.3 x H114.4 (mm)
3-axis bracket adjustment
angle
pan: 280°, tilt: 30°~90°, rotation: 100°
Net weight 1200g
Temperature and humidity
-15°C~50°C, 20%~90% Cold Start
-50°C~50°C, 20%~90% Operating
IP Rating IP68
IK Rating IK10
