FV3028-RT/FV3028-RTM
Model FV3028-RT FV3028-RTM
Lens spec. CBC AG3Z0312LMRP-N CBC AGP3Z0312LMRP-E111T51
Lens type vari-focal Lens (Board mount, M19)
F/no F/1.2
Iris type DC Iris
Focal length f3~9mm
View Angle
H 96.4°(W)~31.7°(T)
V 69.6°(W)~23.7°(T)
MFZ support N//A Yes
Camera image
Min. illumination
0.8 Lux in day mode (IR off)
0.1 Lux in night mode (IR off)
0 Lux in night mode (IR on)
Built-in LED Yes
IR distance 30M
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 2048 x 1536
Frame rate
2048 x 1536 @ 20fps (Wide Angle)
1920 x 1080 @ 30fps (Normal mode)
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
Smart Stream Yes, 5 windows
Image orientation mirror, flip
Motion Detection zones 3
