AVer Bullet type IP cam(E) Installation Guide - Manual (Page 13)

11
ENGLISH
Technical Specifications

FB2027-1 (E) / FB2027-3 (E)
Model FB2027-1 (E) FB2027-3 (E)
Lens spec. PTN-2M4016IR PTK-2M2812N14IR
Lens type
fixed focal Lens (Board Mount
M12 P0.5)
vari-focal Lens (Board mount,
M14)
F/no F1.6 F1.4
Iris type Fixed DC Iris
Focal length 4.0mm 2.8~12mm
View Angle
H 60°
V 34.4°
H 83.3°(W)~28.1°(T)
V 49.5°(W)~17.2°(T)
Camera image
Min. illumination
0.8 Lux in day mode (IR off)
0.15 Lux in night (IR off)
0 Lux in night mode (IR on)
Built-in LED Yes
IR distance 30M
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 1920 x 1080
Frame rate 1920 x 1080 @ 30fps
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
Smart Stream Yes, 5 windows
Image orientation mirror, flip
Motion Detection zones 3
