Alumax ABB Series - Manual (Page 3)

3
06.10-K
ABB32-ABB36-ABB40
PENCIL DRILL SILICONE
LEVEL
TAPE MEASURE DRILL BITS 3/16˝
SPECIFICATION.
SCREW #8 1 1/4˝
(Preferably stainless steel screws)
TOOLS AND MATERIALS REQUIRED.
Model Dimensions*
A B C D E
ABB32
32”
[81.3cm]
32”
[81.3cm]
5 1/2"
[14cm]
12”
[30.5cm]
12”
[30.5cm]
ABB36
36”
[91.4cm]
36"
[91.4cm]
5 1/2"
[14cm]
12”
[30.5cm]
12”
[30.5cm]
ABB40
40 5/16”
[102.5cm]
40 5/16”
[102.5cm]
5 1/2"
[14cm]
12”
[30.5cm]
12”
[30.5cm]
* Tolerance on dimensions: ±1/4” [.6 cm]
DRAIN
