OOLS LIST
PAGE 2
PENCIL DRILL MEASURE TAPE LEVEL SILICON
PACKAGING CHECK LIST & HARDWARE
1/8”
DRILL BIT CERAMIC DRILL BIT TILE
1/4”
MALLET
SET OF HANDLES (2) SIDE GASKET 4)
4 5 8 9
10 12 13 14
SCREW 1 3/8” LG (14)
SCREW ½” LG (4)
SCREW CAP (8)
15
(M4 X 35)
(M4 X 8)
SCREWDRIVERS
HEX NUT DRIVER
MAGNETIC DOOR
GASKET (2)
16 17
GLASS SUPPORT /L (4) GLASS SUPPORT /R (4)
SIDE GASKET (2) WALL JAMB SIDE
OR
(FOR ‘’ POINT ’’
GLASS ONLY)
PARIS
SCREW 3/8” LG (8)
(M4 X 8)
WALL PLUG (8)
