Alumax M-94X User Manual
Page 13
P
U
SUPPORT BAR (2)
(See Addendum)
SCREW 3/8” LG + SCREW CAP (6)
NON / NO
Step
Step
A
B
INTERIOR
SHOWER SIDE
Step
SUGGESTION
USE A LONG NOSE LOCKING PLIERS
TO TEMPORARILY HOLD
THE FIXED PANEL IN PLACE
PAGE 10
SHOWER DOOR INSTALLATION STEPS
PRIOR TO FASTENING DOOR ASSEMBLY,
VERIFY MAGNETIC DOOR GASKET ALIGNMENT
AND ALL PANELS SHOULD BE LEVELED.
13
14
15
LEVEL FIXED PANELS
