Cd b – Alumax P-DR3W-72 User Manual
Page 8
8
1
PLACE AGAINST FRONT
THRESHOLD
A
C
D
B
5
COMPONENTS PLACEMENT
DIMENSION A= 4’’ FROM FINISHED WALL
DIMENSION B= RETURN PANEL (INCLUSIVE OF EXPANDER) - 2’’ FROM FINISHED WALL
DIMENSION C= 4’’ FROM SIDE THRESHOLD
DIMENSION D= FIXED PANEL + 11/16’’ FROM SIDE THRESHOLD
!
ILLUSTRATION SERVES TO
REPRESENT AN INSTALLATION
WITH DOOR CLOSING ON LEFT.
FOR DOOR CLOSING ON RIGHT,
MEASURE PLACEMENT OF FRONT
THRESHOLD COMPONENTS FROM
LEFT THRESHOLD.
