L AYO U T A N D F E AT U R E S
PA G E 1
O
I
Power Switch
12-24 V DC Power From Driver
Out to LEDs
LCD Display
Control Buttons
Power Input
USB Terminal
Block
RJ45 3-Pin XLR
DMX Input / Output Options
