8 Insert Spring Clip (G) into the cut out area
and align with the pilot hole. Screw the
Spring Clip into place.
I N S TA L L AT I O N - - S T E P 8 - 9
9 Snap the channel (A) into the cut-out area
so that the channel flanges sit flush with the
mounting material.
(B)
(G)
(A)
