LG WD-12380TP - Manual (Page 4)

pedfication
Drawer
(For detergent and
fabric softener)
Door
Power plug
If the supply cord is damaged,
it must be replaced by the
manufacturer or its service agents
or a similarly qualified person in
order to avoid a hazard.
Control panel
Drum
Lower cover
Adjustable feet
Drain pump filter
Drain plug
Lower cover cap
WD-80/10/1238(0~9)S(U)P WD-80/10/1238(0~9)N(U)P WD-80/10/1238(0~9)T(U)P
Name Front loading washing machine
Power supply 220-240V-, 50Hz
Size 600mm(W)x360mm(D)x850mm(H) 600ttim(W)x440ttim(D)x 850mm(H) 600mm(W)x 550mm(D)x850mm(H)
Weight / Max. Watt 55 kg/2100 W 60 kg/2100 W 65 kg/2100 W
Wash capacity 3.5 kg 5 kg 7 kg
Water
consumption
42L 55L 69 L
Permissible water
Pressure 0.3-10 kgf / cm2 (30-1 OOOkPa)
Spin Speed
/ 400 / 500 / 600 / 800 [WD-8038(0~9)S/N/T(U)P]
/ 4 0 0 / 6 0 0 / 8 0 0 / 1000 [WD-1038(0~9)S/N/T{U)P]
/ 400 / 8 0 0 / 1000 / 1200 [WD-1238(0~9)S/N/T(U)P]
^ The appearance and specifications may be varied without notice to raise the units quality.
