MARCH 2009
REV. 03/05
PART DESCRIPTION
REF. NO. PART NO. LIST PRICE
16" Vent Enclosure Side
1
31360
9.10
$
16" Vent Enclosure Front
2
31355
11.40
$
24" Vent Enclosure Side
1
31367
14.00
$
24" Vent Enclosure Front
2
31366
17.20
$
36" Vent Enclosure Side
3
31385
17.00
$
36" Vent Enclosure Front
4
31380
21.00
$
Side / Rear Register
5
31630
20.00
$
Side Register
6
31525
20.00
$
Large Outer Boot
7
31580
26.10
$
Large Inner Boot
8
31560
23.70
$
Small Outer Boot
9
31720
10.80
$
Small Inner Boot
10
31710
10.20
$
Boot Trim
11
31615
17.60
$
Plaster Ground
12
31595
12.90
$
Side Boot
13
31510
10.30
$
Cabinet Side Trim Angle
14
31310
5.90
$
Cabinet Top Trim
15
31320
5.10
$
Damper Assembly
16
31675
22.90
$
Black 17-1/2" Fork Term./with Stripped end Transformer (24 V. Side) to Thermostat
78200
1.70
$
Black 27" Flag Terminal/Flag Terminal Auxiliary Limit Switch to Valve
78205
2.20
$
Wiring Harness
78250
26.20
$
Black 17-1/2" Fork Term./with stripped end Transformer (24 V.) to Thermostat
78200
1.70
$
Black 32" Flag Terminal/Flag Terminal Auxiliary Limit Switch - Valve
78216
2.10
$
Black 6" Flag Terminal/Flag Termial Selector Switch - Fan Switch
78208
1.80
$
Wiring Harness
78251
26.20
$
Black 17-1/2" Fork Term./with stripped end Transformer (24 V.) to Thermostat
78200
1.70
$
Black 32" Flag Terminal/Flag Terminal Auxiliary Limit Switch - Valve
78216
2.10
$
Black 6" Flag Terminal/Flag Terminal Selector Switch to Fan Switch
78208
1.80
$
Wiring Harness
78252
26.20
$
Black 17-1/2" Fork Term./with stripped end Transformer (24V. Side) to Thermostat
78200
1.70
$
Black 30" Flag Terminal/Straight Terminal Auxiliary limit to ignition control box
78214
2.10
$
Wiring Harness
78259
26.20
$
Black 17-1/2" Fork Term./with stripped end Transformer (24V.) to Thermostat
78200
1.70
$
Black 38" Flag Terminal/Straight Terminal Auxiliary limit to ignition control box
78258
2.50
$
Black 6" Flag Terminal/Flag Terminal Selector Swith - Fan Switch
78208
1.80
$
Wiring Harness
78257
29.90
$
REPLACEMENT WIRING - STANDING PILOT COUNTERFLOW
PARTS LIST FOR ACCESSORIES FOR COUNTERFLOW WALL FURNACE
MODELS CF357C & CF358C
MODELS CF557C & CF558C
MODELS CF653C & CF654C
MODELS CF503C & CF504C
MODELS CF353C & CF354C
REPLACEMENT WIRING - I.I.D. (INTERMITTENT IGNITION) COUNTERFLOW
Mr. Contractor, we only sell parts through our wholesalers, but the prices listed above are for your
convenience. For prompt parts service, contact the wholesaler from which you purchased your Cozy heater.
NOTE: Parts & schematic drawings on current models are shown at www.cozyheaters.com.
