Page 21 * REQUIRES TWO
REV. 03/2005
MARCH 2009
HOW TO PROPERLY ORDER PARTS: In addition to part description and part number, please give model number, serial
number, and type of gas used. This information can be found on the rating plate that is attached to heater.
NAT URAL
MODEL NUMBER L.P . CF654C-H
REF. P ART LIST P ART LIST P ART LIST
P ART DESCRIP T ION NUMBER NUMBER P RICE NUMBER P RICE NUMBER P RICE
Casing Side, Right 1 30055 53.80 $ 30325 54.60 $ 30525 58.00 $
Casing Side, Left 1a 30060 53.80 $ 30330 54.60 $ 30530 58.00 $
Cent er Back Assem bly 1b 30114 41.30 $ 30364 38.10 $ 30544 40.90 $
T op Assem bly 1c 30025 14.80 $ 30025 14.80 $ 30025 14.80 $
Upper Back Assem bly 1d 30070 24.80 $ 30070 24.80 $ 30070 24.80 $
Lower Back Assem bly 1e 30219 34.00 $ 30219 34.00 $ 30219 34.00 $
Bot t om 1f 30246 10.90 $ 30246 10.90 $ 30246 10.90 $
Liner Assembly 2 30120 81.60 $ 30370 82.40 $ 30550 89.30 $
Header Assem bly Com plet e 3 31399 42.90 $ 31399 42.90 $ 31399 42.90 $
Heat Exchanger Assembly 4 30133 234.40 $ 30379 240.50 $ 30563 240.50 $
Draft Divert er Assem bly 5 30180 34.90 $ 30400 47.10 $ 30400 47.10 $
Fan Shroud Assem bly 6 30200 24.10 $ 30200 24.10 $ 30200 24.10 $
T op Louver w/Insulat ion 7 30087 19.60 $ 30087 19.60 $ 30087 19.60 $
Cent er Front P anel w/Insulat ion 8 30089 27.70 $ 30359 29.70 $ 30534 32.00 $
Bot t om Louver Assembly w/Insulat ion 9 30100 35.20 $ 30100 35.20 $ 30100 35.20 $
Upper Front Shield 10 30250 3.90 $ 30250 3.90 $ 30250 3.90 $
Swit ch Box 11 30252 8.00 $ 30450 8.10 $ 30450 8.10 $
Swit ch Box Cover 12 30253 3.10 $ 30253 3.10 $ 30253 3.10 $
Lower Front Shield 13 30256 5.70 $ 30256 5.70 $ 30256 5.70 $
Mot or Mount ing Bracket 14 * 30079 2.30 $ *30079 2.30 $ *30079 2.30 $
Junct ion Box Cover 15 30033 4.10 $ 30033 4.10 $ 30033 4.10 $
Burner 16 72107 42.50 $ 72107 42.50 $ 72107 42.50 $
Valve, VR8200H-1004 Natu ral Gas w/78089 Di s. B u sh i n g 17 78090 139.20 $ 78090 139.20 $ 78090 139.20 $
Valve, VR8200H-1103 L.P. GAS w/78089 Di s. B u sh i n g 18 78091 143.80 $ 78091 143.80 $ 78091 143.80 $
Disappearing Bushing 1/2 x 3/8 78089 2.20 $ 78089 2.20 $ 78089 2.20 $
W iring Harness 19 78250 26.20 $ 78251 26.20 $ 78257 29.90 $
Manifold 21 78006 13.70 $ 78006 13.70 $ 78006 13.70 $
Orifice,NATURAL 22 72182 3.80 $ 78160 3.80 $ 78169 3.80 $
Orifice, L.P. 23 95271 3.80 $ 78163 3.80 $ 95273 3.80 $
Fan Mot or 24 72108 82.30 $ 78111 95.50 $ 78111 95.50 $
Fan Blade 25 78101 26.90 $ 78101 26.90 $ 78101 26.90 $
Rubber Gromm et 26 78010 3.40 $ 78010 3.40 $ 78010 3.40 $
Lim it Swit ch 60T 11-L180 27 78065 6.60 $ 78065 6.60 $ 78065 6.60 $
Fan Swit ch 60T 12-F120 28 78067 6.80 $ 78067 6.80 $ 78067 6.80 $
Speed Swit ch 60T 13-F160-30 29 N/A N/A 78066 9.90 $ 78066 9.90 $
Auxiliary Lim it Swit ch 60T 15-L350 30 78086 10.40 $ 78086 10.40 $ 78086 10.40 $
T hermost at 24 Volt 31 78355 22.30 $ 78355 22.30 $ 78355 22.30 $
T ransformer 32 78069 26.20 $ 78069 26.20 $ 78069 26.20 $
Flue P ipe Adapt er 32b 40061 2.20 $ 40061 2.20 $ 40061 2.20 $
P lug Bracket 32c 30047 2.10 $ 30047 2.10 $ 30047 2.10 $
Casing Mount ing Bracket s 32d *30260 1.40 $ *30260 1.40 $ *30260 1.40 $
Flue P ipe Gasket 33 78050 1.40 $ 78050 1.40 $ 78050 1.40 $
Draft Divert er Gasket 34 78051 1.40 $ 78051 1.40 $ 78051 1.40 $
Casing T op Gasket 34b 78155 1.40 $ 78155 1.40 $ 78155 1.40 $
Element Support Gasket 35 78052 4.90 $ 78052 4.90 $ 78052 4.90 $
P ilot ,NAT. 0.140.512 36 72020 25.20 $ 72020 25.20 $ 72020 25.20 $
P ilot , L.P.. 0.140.502 36 72021 25.20 $ 72021 25.20 $ 72021 25.20 $
Cozy Handle 37 84003 2.50 $ 84003 2.50 $ 84003 2.50 $
P ower Cord 38 78213 5.20 $ 78213 5.20 $ 78213 5.20 $
Snap-in Out let 39 78058 5.20 $ 78058 5.20 $ 78058 5.20 $
T hermost at W ire 41 74518 1.50 $ 74518 1.50 $ 74518 1.50 $
T hermocouple Q309A-2135 42 78095 12.70 $ 78095 12.70 $ 78095 12.70 $
Insulat ed St aples 43 74209 1.40 $ 74209 1.40 $ 74209 1.40 $
Door Cat ch 44 80005 1.40 $ 80005 1.40 $ 80005 1.40 $
Blocked Flue Swit ch 45 78108 10.40 $ 78109 10.40 $ 78109 10.40 $
Blocked Flue Swit ch W ire 46 78230 1.70 $ 78230 1.70 $ 78230 1.70 $
T erminal Board 52 78300 5.60 $ 78300 5.60 $ 78300 5.60 $
P ilot T ubing w/Fit t ings -- 78452 6.00 $ 78452 6.00 $ 78452 6.00 $
P iezo Sparker -- 80016 6.40 $ 80016 6.40 $ 80016 6.40 $
Elect rode W ire -- 72022 5.20 $ 72022 5.20 $ 72022 5.20 $
Burner P an Assembly 53 30286 17.70 $ 30286 17.70 $ 30286 17.70 $
Valve Support Bracket Assembly 56 30290 5.20 $ 30290 5.20 $ 30290 5.20 $
P ilot Mount ing Bracket 57 30299 2.70 $ 30299 2.70 $ 30299 2.70 $
Burner Mount ing P lat e 58 30296 3.10 $ 30296 3.10 $ 30296 3.10 $
Light ing Inst ruct ions "CF" -- 91272 N/C 91272 N/C 91272 N/C
24 VO LT S YS TEM W ITH LO W -B .T.U. S TANDING PILO T
CF353C-H
CF354C-H CF503C-H
CF504C-H CF653C-H
Mr. Contractor, we only s ell parts through our wholes alers , but the prices lis ted above are for your convenience. For prom pt parts
s ervice, contact the wholes aler from which you purchas ed your Cozy heater. NOTE: Parts & s chem atic drawings on current m odels
are s hown at w w w .cozyheaters.com.
