ENGINE PARTS
CRAFTSMAN 2400 PSI HIGH PRESSURE WASHER 919.670280
BRIGGS ENGINE MODEL #120612-0152-E10
365
125
141
633 I
131
633 A©
692 I
843 3341
333
851
356
188
202
REF PART
1
REF PART REF PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
51 692668 Intake Gasket 134 398188 Needle/Seat Kit 365 691136 Screw (Carburetor)
95 691636 Screw (Throttle 137 693981 Float Bowl Gasket 621 692310 Stop Switch
Valve) 141 693866 Choke Shaft Kit 633 693867 Choke/Throttle Shaft
104 691242 Float Hinge Pin 163 692667 Air Cleaner Gasket Seal
108 691182 Choke Valve 188 691147 Screw 633A 691321 Choke/Throttle Shaft
117 692677 Main Jet (Control Bracket) Seal
117 ---------Note---------- 202 691303 Mechanical Governor 692 690572 Detent Spring
117 497315 Main Jet Link 843 691884 Lever Sleeve
(High Altitude) 209 691290 Governor Spring 851 493880 Sparkplug Terminal
122 692799 Carburetor Spacer 222 693378 Control Bracket 975 493640 Float Bowl
125 694505 Carburetor 276 271716 Sealing Washer
127 694468 Vtfelch Plug 333 802574 Magneto Armature
130 691203 Throttle Valve 334 691061 Screw
131 499682 Throttle Shaft Kit (Magneto Armature)
133 398187 Carburetor Float 356 692390 Stop Wire
23-ENG
