PARTS
CRAFTSMAN 2400 PSI HtGH PRESSURE WASHER 919.670280
24
REF NO. PART NUMBER
DESCRIPTION
1
D20588
2
0042
3
17628
4
17709
5
W137
6
17926
7
W131
8
17713
11
D20587
12
D20181
13
17569
14
F064
15
F469
16
17712
17
17716
19
17367
900
20
PK18148
23
F112
24
AL-650015
Handle, Bagged
Knob - 5/16”
Gun
Tire Semi (8x2")
Nut Pal 1/2"
Rubber Foot, Hollow
Tee Nut 5/160" x 3/4”
Frame
Wand,High Pressure Soap
Hose. 1/4" X 25 ft.
Decal Craftsman
Screw - Hex 5/16" - 18 x 1LG
Lock Nut 5/16”
Screw HHC, 5/16”
Decal Operation
Handle Grip
Engine (Refer to Engine Break
down (Model 120612-0152-El
Pump
Washer
0-Ring Kit
PARTS NOT ILLUSTRATED
D20590
Owners Manual
NCT001
Nozzle Cleaning Tool
D20667
2 mm Allen Wrench
16806
5 mm Allen Wrench
F101
Screw, Hex-Engine to Pump
FI 96
Screw, Hex-Engine to Pump
16087
Nut Flanghead-Engine to Pump
F074
Washer Flat-Engine to Pump
17658
Thermal Relief Valve
0013
Screen, Filter
D20044
Soap Hose
0
)
ACCESSORIES
(Not Included with Pressure Washer)
919.76430 Floor/Siding Brush
919.76431 Fixed Brush
919.76450 25Ft. 3/8” high pressure hose
919.76451 50Ft. 3/8" high pressure hose
919.76484 Turbo nozzle
