TRACTOR -- MODEL NUMBER 917.276361

SCHEMATIC

SHORTING CONNECTOR

NOTIN REVERSE

ELECTRIC C LUTCH

BLACK / WHITE

IGNITION

UNIT

SPARK PLUGS

GAP •—

(2 PLUGS

ON TWIN CYL ENGINES)

FUEL S HUT-OFF

SOLENOID _

I A FUEL ^

HOUR

METER

(OPTIONAL)

(IF SO EQUIPPED)

REGULATOR

¡ALTERNATOR

RE-ilfLAT HCi^

IGNITION SWITCH

POSITION CIRCUIT “MAKE”

OFF

M+G+A1

RUN/OVERRIDE

B+A1

RUN

B+A1 L+A2

START

B + S +A1

NOTE

YOUR TRACTOR IS

EQUIPPED WITH A SPECIAL

ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT
CONNECTED TO THE

BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED. AT IDLE THE LIGHTS
WILL DIM. AS THE ENGINE IS
SPEEDED UP, THE LIGHTS

' WILL BECOME THEIR BRIGHTEST.

HEADLIGHTS

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CLIPS

NOTE: IF WIRING INSULATED CLIPS
WERE REMOVED FOR SERVICING OF

UNIT, THEY SHOULD BE REPLACED

TO PROPERLY SECURE YOUR WIRING.
