REPAIR PARTS FOR MODEL 486.248531 42" SNOW THROWER
Fi Ei“
NO.
part
NO.
QTY. DESCRIPTION REF.
NO.
PART
NO.
QTY. DESCRIPTION
1 05931 1 Housing, Bearing 56 741-0919 2 Bearing, Ball
2 64184 1 Housing Assembly 57 08253B 1 Housing, Bearing
3 618-0616 1 Gear Assembly 58 15296A 1 Housing, Open Bearing
4 63579 1 Chute Crank Rod Assembly 59 14088B 1 Spacer, Spindle
5 63768 1 Impeller Assembly 60 44377 2 Hex Bolt, 3/8-24 x 1"
6 24773 1 Scraper Plate 61 736-0247 3 Washer,
7 703-2734 1 Bracket, Housing Brace 62 43063 3 Hex Bolt, 5/16-18 X 1"
8 703-2735A 1 Bracket, Chute Crank 63 48138 1 Belt, V Type Drive
9 24816 1 Cover, Belt 64 47846 1 Beit, V Type Auger
10 705-5226 1 Chute Reinforcement 65 47044 3 Pulley, V Type 4"
11 705-5269 1 Spirai Assembly, L.H. (not shown) 66 47026 1 Pulley, V Type
12 705-5270 1 Spiral Assembly, R.H. 67 47025 1 Hex Bolt, 5/16-18x3-1/2"
13 43182 2 Hex Bolt, 5/16-18x3/4" Lg. 68 43432 1 Hex Bolt, 3/8-16x2-1/2"
14 44950 5 Carriage Bolt, 1/4-20 x 3/4" 69 731-0851A 3 Chute Keeper
15 44917 1 Palnut, 3/8" 70 43661 6 Hex Bolt, 1/4-20 x 1"
16 44326 4 Carriage Bolt, 5/16-18 x 1" Lg. 71 43054 3 Hex Bolt, 3/8-16x2"
17 43080 11 Carriage Bolt, 5/16-18 x 3/4" Lg. 72 731-1300A 1 Chute, Lower
18 46703 6 Bolt, Self-Tap 5/16" x 3/4" 73 710-0896 1 Screw, 1/4-14x5/8"
19 710-0890A 2 Bolt, Shear 5/16-18x1-1/2" 74 43681 1 Carriage Bolt, 5/16-18x1 -1 /2"
20 43088 5 Washer, 1/4" 75 24571 1 Spacer
21 43064 33 Hex Lock Nut, 5/16-18 Thd. 76 731-1320 1 Chute, Upper
22 43013 5 Hex Lock Nut, 1 /4-20 77 731-1313C 1 Guide, Cable
23 43083 4 Hex Nut, 5/16-18 78 784-5594 1 Bracket, Cable
24 715-0114 2 Spirai Pin, 1/4"
X
1-1/2" Lg. 79 24472 1 Spacer, Pivot
25 750-0437 2 Bushing 80 746-0929 1 Cable, Chute Control With Clip
26 731-1379A 1 Chute Adapter 81 746-0928 1 Cable, Chute Control
27 43086 19 Lock Washer, 5/16" 82 43070 7 Washer, 3/8"
28 736-0188 6 Washer, .76" x 1.49" x .06" 83 46959 1 Spring
29 711-0469 4 Spacer, .75 ID x 1.25 OD x .5 L 84 46963 2 Chain
30 43081 16 Washer, 5/16" Std. Wrt. 85 43055 1 Pin, Hair Cotter, 3/32"
31 47615 2 Bearing, Flange 86 43038 2 Pin, Pivot Lock
32 741-0309 1 Bearing, Bail 88 43088 6 Washer, 1/4"
33 741-0475 2 Bushing, Plastic 3/8" 89 43343 4 Pin, Hair Cotter #4 (1/8")
34 741-0493A 4 Bearing, Split, 3/4" 90 43350 4 Carriage Bolt, 3/8-16 x 1"
35 24279 2 Skid Shoe 93 1 Bracket, Chute Anti-rotation
36 2^29^ 1 Frame Clutch and Pulley 94 1643-60 1 Plastic Cap
37 784-5618 2 Housing, Bearing 95 64452 1 Hanger Bracket Assembly, R.H.
38 24393 1 Bracket, Chute Crank 96 64451 1 Hanger Bracket Assembly, L.H.
39 24281 1 Bracket, Idler 99 48106 4 Bolt, Shoulder
40 63904 1 Idler Arm Assembly 100 24466 2 Bracket, Down Stop
41 24286 1 Spacer, Pivot 101 47620 1 Spring
42 63762 1 Idler Bracket Assembly 102 47607 1 Spring, Torsion
43 41576 2 Hex Bolt, 3/8-16x1-3/4" 103 23625 1 Spacer
44 44377 1 Hex Bolt, 3/8-24x1" 104 43509 1 Hex Bolt, 3/8-16 x 2-3/4" Lg.
45 756-0405 1 Pulley, Flat 3-3/4" 105 47598 6 Hex Lock Nut, 1/4" Wash. Face
46 43015 1 Hex Nut, 3/8-16 108 43796 1 Hex Bolt, 1/4-20x2-3/4"
47 711-0242 1 Spacer 109 43178 2 Hex Nut, 1/4-20
48 46981 1 Pulley, V Type 9" 110 43177 1 Lock Washer, 1/4"
49 43082 17 Nut, Hex Lock, 3/8-16 111 48883 1 Pulley, Flat 3-5/8"
50 46982 1 Pulley, V Type 5-1/2" 48935 1 Owner's Manual
51 738-0680 1 Shaft
52 750-0456 1 Spacer
53 750-0660 1 Spacer
54 43003 14 Lock Washer, 3/8"
55 714-0161 2 Key
21
