COMMERICAL LEAF and LAWN VACUUM Safety & Operating Instructions
Parts List — Centrifugal Separator, Hose & Blower Exit
Elbow Assembly
Note: Part numbers listed are available through Country Home Products.
Ref# Part# Description
01 186831
Centrifugal
Separator
02
114781 Screw, Pan Head, 10-24 X 5/8"
03
118731 Nut, Nylon Lock, 10-24
04
112371 Washer, Flat, 10-24 USS
05
175521 Bolt, Eye, 10-24 X 1/2"
06 186731
Latch,
Draw
07 186811
Rod,
Threaded, 3/8"-16 X 8"
08
110751 Nut, Nylon Lock, 3/8"-16
09
112391 Washer, Flat, 3/8", USS
10 186801
Cone,
Centrifuge
11
188971 Rivet, Nut, Closed End, 10-24
12 Deleted
13 126831
Nut,
3/8"-16,
ZP
14
186741 Hose, Male/Female to Centrifugal Separator, 76"
15
186961 Clamp, Hose, 6"
16
186771 Adapter, Male/Female, 6"
17
164141 Rivet, Pop, Alum., 3/16" Dia. X .1875"
18
189291 Rivet, Pop, Alum., 3/16" Dia. X .312"
19
190701 Elbow, Blower Exit
20
189331 Nut, Wing, Nylon Lock, 5/16"-18
21
187621 Bolt, RHSNB, 5/16"-18 X 1"
22
189441 Keeper, Draw Latch, 4"
23
190021 Washer, Backing w/Tab
24
112381 Washer, Flat, 1/4" USS
25
190571 Adapter, Hose to Chipper/Vacuum
