Craftsman 917.274810 - Manual (Page 37)

TRACTOR - - MODEL NUMBER 917.274810
GROUND DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 Transaxle Peerless 206-545C 62 8883R Cover, Pedal
(See Breakdown) 63 175410 Pulley, Engine
2 146682 Spring, Return, Brake 64 173937 Bolt, Hex 7/16-20 x 4 Gr. 5
3 123666X Pulley, Transaxle 65 STD551143 Washer
4 12000028 Ring, Retainer 66 154778 Keeper, Belt, Engine, Fool-Proof
5 121520X Strap, Torque 69 142432 Screw HexWsh Hi-Lo 1/4-1/2 unc
6 17060512 Screw 5/16-18 X 3/4 70 134683 Guide, Mower Drive Belt, R.H.
8 192502 Rod Shifter Fender STLT 74 137057 Spacer, Axle
10 STD561210 Pin, Cotter 75 121749X Washer 25/32 x 1-1/4 x 16 Ga,
11 105701X Washer, Shift Plate 76 STD581075 E-Ring
13 74550412 Bolt 1/4-28 unfW/PatchGr, 8 77 123583X Key, Square 2.0 x .1845/.1865
14 10040400 Washer Lock Hvy Helical 78 121748X Washer 25/32 x 1-5/8 x 16 Ga.
15 74490544 Bolt Hex FIghd 5/16-18 Gr. 5 79 STD580025 Key Woodruff
16 73800500 Nut Lock HxW/lns 5/16-18 80 145090 Arm, Shift
18 STD523710 Bolt Fin Hex 3/8-16 unc x 1 Gr. 5 81 165592 Shaft Asm Cross Tapered
19 STD541437 Nut 82 165711 Spring, Torsion
21 106933X Knob 83 19171216 Washer 17/32 x 3/4 x 16 Ga.
22 130804 Rod, Brake 84 166231 Link Transaxle
24 STD541237 Nut 85 150360 Nut, Nylock
25 106888X Spring, Brake Rod 89 192388X428 Console, Shift, STLT
26 STD551037 Washer 96 STD624003 Retainer Spring
27 STD561210 Pin 112 19091210 Washer 9/32 x 3/4 x 10 Ga.
28 175765 Rod, Parking Brake 113 127285X Strap Torque 90 Degrees
29 71673 Cap, Parking Brake 116 72140608 Bolt Rdhd Sqneck 3/8-16 x 1
30 169592 Bracket, Transaxle 120 73900600 Nut Lock Fig. 3/8-16
32 STD523107 Bolt 150 175456 Spacer Retainer
34 175578 Shaft Assembly, Foot Pedal 151 19133210 Washer 13/32x2x 10 Ga.
35 120183X Bearing, Nylon 156 166002 Washer Srrted 5/16 ID X 1.125
36 STD551062 Washer 158 165589 Bracket Shift Mount
37 STD571810 Roll Pin 159 183900 Hub Shift
38 179114 Pulley, Composite, Flat 161 72140406 Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr.5
39 72110622 Bolt Rdhd 3/8-16 unc x 2-3/4 Gr, 5 162 73680400 Nut Crownlock 1/4-20 unc
41 175556 Keeper, Belt, Idler 163 74780416 Bolt Hex Fin 1/4-20 uncx 1 Gr. 5
47 127783 Pulley, Idler, V-Groove, Plastic 165 165623 Bracket Pivot Lever
48 154407 Bellcrank Clutch Grnd Drv StI 166 17490510 Screw 5/16-18 X 5/8
49 123205X Retainer, Belt 168 165492 Bolt Shoulder 5/16-18 x.561
50 72110612 Bolt Carr. Sh. 3/8-16
X
1-1/2 Gr. 5 169 165580 Plate Fastening Lt
51 STD541437 Nut Crown Lock 3/8-16 unc 170 187414 Keeper Belt Transaxle Gear
52 STD541431 Nut Crown Lock 5/16-18 unc 198 169593 Washer Nylon
53 10571OX Link, Clutch 202 72110614 Bolt Carr. SH 3/8-16 x 1-3/4 Gr. 5
55 105709X Spring, Clutch Return 212 145212 Nut Hex Fig. Lock
56 17060620 Screw 3/8-16
X
1-1/4
57 130801 V-Belt, Ground Drive
59 169691 Keeper, Belt, Center Span NOTE: All component dimensions given in U. S.
61 17120614 Screw 3/8-16
X
.875 inches 1 inch = 25.4 mm
37
