Craftsman 580.768030 - Manual (Page 25)

Craftsman 2250 PSI Cleaning System 580.768030
Main Unit
Item Part# Qty Description
2 B3608C 1 LINK, Throttle Control
3 B3597 1 DECAL, Control Panel 2250
4 B3376B 1 TAG, System Flush Water
5 B3222D 1 CAP, Chem Container
"Water-
6 B3222A 1 CAP, Chem Container “A”
7 B3594 4 ASSY., Chemical Tank 1/2
Gal. •.
8 B3222B 1 CAP, Chem Container “B"
9 B3222C 1 CAP, Chem Container “C”
10 B3695 8 BOLT, 1/4"- 20 with Viasher
11 EB3265 1 CRADLE, Polo Green
12 96307 1 DECAL, 1-800 Number
13 86292 4 SELF DRILL, 10-16x3/4"
14 B3311 1 SCREW, Plastite 10-9
15 B3721 1 HANDLE, 4-Way Valve
16 B3377 3 SCREW, Plastite 8-11 3/4"
17 EB3113 1 PANEL, Control Polo Green
18 91526 2 SCREW, M5 -0.8x 12
19 49226 2 LOCK WASHER, M5
20 51716 2 NUT, Hex M5 - 0.8
21 B3306 1 ASSY,, Sub 4-Way Valve
22 B3593A 1 HOSE, “A" - 6.5"
23 В35ЭЗВ 1 HOSE, “B” - 8.5"
24 B3593C 1 HOSE, “C”-11.0"
25 B3593D 1 HOSE, “Water” - 8"
26 B3601D 1 HOSE, Chemical Pump
10.5"
27 48031G 4 CLAMP, Hose 3/16"
28 EB2555 1 HANDLE, Polo Green
29 B2071 2 NUT, 1/4" - 20 Flange
Locking
30 46476 2 CAP PLUG, Tubing
31 31669 1 BOLT. 1/4"-20 X 1-3/4"
Carriage
32 В177Э 2 COVER, Hinge
33 B2347 2 END CAP, Tube
34 B1460 1 CAP, Vinyl Black
35 B2759 1 HOOK, Square Neck Gun
36 B3741 1 AXLE ROD, 1/2" ;c 21.53"
37 B1760 2 ASSY., Wheel & Tire 10"
38 75402 2 PUSHNUT, 1/2"
39 52858 2 NUT, M8 -1.25 Locking
Item Part# Ш Description
40 27007 2 MOUNT, Vibration Donut
Type
41 50190 2 FLAT WASHER, M8
42 42909 2 HHCS, M8 x 1.25 X 30 Long
43 97100 1 CAP, Outlet
44 21424 1 CONNECTOR, Garden
Hose
45 B3700D 1 ASSY., Pump
46 A1408 1 CAP, Inlet
47 21217 4 MOUNT, Rubber Shock
48 67989 8 NUT, Hex Locking Flange
M8
49 92659 1 NOZZLE, Replacement
52 B3607 1 HOSE, 1/4"
X
25’
53 97566 1 TAG, Nozzle Instructions
54 B3335B 1 WAND, Nozzle Hi/Lo
55 B3263 1 GUN, High Pressure
56 AB3061B 1 OIL BOTTLE, 20 oz
57 B3708 1 KIT, Cleaning Nozzle
58 B2730 1 KIT, Maintenance
59 B3454 1 KIT, Tag
60 B3589 1 КГТ, 3 Pak Concentrate
61 B3595 1 MANUAL
62 B3453 1 DECAL, Start Instructions
63 48031C 2 CUMP, Hose 1/2"
64 B1288 1 TAG, Breather
900 NSP 1 ENGINE
Optional Accessories Not Illustrated:
71-74300 House Wash Concentrate
71 -74301
Deck Wash Concentrate
71-74302 Vehicle Wash Concentrate
71-74303 Degreaser Concentrate
71 -74400 Heavy Duty Tuibo Nozzle
71 -74401 25’ 3/8" Replacement Extension Hose
71 -75115 25’ 1/4" Replacement Hose
71 -75116 O Ring Repair Kit
71-75187 Garden Hose Quick Connect
71-75197 Accessory Quick Connect Kit
71-75199 Rotating Brush
71-76430 Floor/Siding Brush
71 -76431 Utility Brush
25
