UNASSEMBLED PARTS
Keys
Slope Sheet
(1) Oil Drain Tube
For Future Use
(2) Keys
ASSEMBLY/PRE-OPERATION
Your new tractor has been assembled at the factory with the exception of those parts left
unassembled for shipping purposes.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly
easier. Standard wrench sizes are listed.
(1) 1/2" wrench
(2) 7/16" wrenches
Pliers Tire pressure gauge
Utility knife LABEL
When right or left hand is mentioned in this
manualjtmeanswhenyouareintheoperating
position (seated behind the steering wheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACK CARTON
• Remove all accessible loose parts and
parts cartons from carton .
• Cut along dotted lines on all four pan­
els of carton. Remove end panels and
lay side panels flat.
• Check for any additional loose parts or
cartons and remove.
BEFORE REMOVING TRACTOR
FROM SKID
CHECK BATTERY
1. Lift hood to raised position.
NOTE: If this battery is put into service
after month and year indicated on label
(label is located between terminals)
charge battery for minimum of one hour at
6-10 amps. (See "BATTERY" in Mainte­
nance section of this manual for charging
instructions).
ADJUST SEAT
1
.
2 .
3.
Sit in seat.
Lift up adjustment lever (A) and slide seat
until a comfortable position is reached
which allows you to press clutch/brake
pedal all the way down.
Release lever to lock seat in position.
