SEARS CRAFTSMAN 4.0 H.R LAWN MOWER MODEL 247.388240
Key
No.
Part No. Description Key
No.
Part No. Description
1.
2.
747-0824
749-0538D- Blade Control Handle
Upper Handle 28. 782-0054A-
0689
Cutting Deck
0637 29. 682-0516 Height Adj. Bracket Assy. RH
3. 749-0928­
0637 Lower Handle 682-0515 Height Adj. Bracket Assy. LH (not
shown)
4. 710-1270 Oval C-SunkScr. 1/4-20 x 1.3' 30. 710-1248 Weld Pin
5. 712-0324 Hex Lock Nut 1/4-20 31. 720-0190 Height Adjustment Knob
6. 746-0883 Cable Housing 32. 732-0404 Spring Lever: Front Wheel
7. 710-1205 Eye Bolt: Rope Guide . 33. 710-0654A Sems Screw TT 3/8-16 x 1,0"
8. 720-0241 Wing Nut 5/16-18 34. 14765 Pivot Bar: 9 Position
9. 736-0451 Saddle Washer 35. 738-0507B Shoulder Screw
10. 710-0450 Carriage Bolt 5/16-18 x 3.0" 36. 734-1841 Wheel 8 X1.7 Aero Gray
11. 720-0279 Handle Knob 1/4-20 37. 738-0102 Shoulder Scr. 3/8-16 x 1.445"
12. 746-0737 Control Cable: 51" 38. 782-5004 Rear Baffle RH
13. 726-0240 Cable Tie 39. 782-5025 Front Baffle
14. 714-0104 Hairpin Clip 40. 736-0356 Bell Washer
15. 782-7025 Chute Door: RD 41. 712-0798 Hex Nut 3/8-16
16. 764-0447 Grass Catcher 42. 15261A Height Adj. Piate
17. 764-0325 Grass Catcher Frame 43. 736-0105 Spring Washer
18. — Engine, Tecumseh model 143.994002 44. 15262B Pivot Bar: Front Wheel
19. 732-0678 Torsion Spring, RH 45. 710-1044 Hex Bolt 3/8-24 x 1.5’ Gr.8 Special
20. 732-0677 Torsion Spring, LH 46. 736-0524A Blade Bell Support
21. 732-0712 Wire: Trail Shield 47. 742-0739 Blade: Mulching
22. 731-1261 Trail Shield 48. 748-0376C Blade /^apter
23. 726-0201 Speed Nut 49. 711-0996 SD Chute Rod
24.
25.
731-1405
782-5007A SD Chute: Kit
Mulch Plug 50. 732-0417A Spring Lever: Rear Wheel
21
