CRAFTSMAN COMPOUND MITER SAW - MODEL NUMBER 315.212110
The model number wi!! be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART KEY F art
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER DESCRIPTION QUAN.
1 710308-045 * Bolt (M8 X 45 Soc, Hd.)............ ............................ 4 15 ** STD851010 * Washer (Ml 0)....................................... ................ 2
2 ** STD852008 * Lock Washer (M8).................... ............................4 16 976511-001 Spring Washer (M10).......................... .................1
3 977443-001 Fence ....................................... ............................1 17 976578-001 * Nylon Lock Nut (M10)......................... .................1
4 976516-001 Zero Clearance Throat Plate ............................ 1 18 700306-025 * Screw (M6 X 25 Soc. Hd. Cap)............. ................ 2
5 160030-400 * Screw (M4 X 6 Flat Hd.)........... ............................4 19 ** STD852006 Lock Washer (M6)............................... ................ 2
6 976514-001 Miter Table............................... ............................1 20 976501-001 Control Arm......................................... .................1
7 976598-001 Cover Plate............................... ............................ 1 21 976505-001 Miter Lock Handle................................ .................1
8 976601-001 * Screw (M4 X 9 Pan Hd.)........... ............................2 22 976506-001 Pointer.................................................. .................1
9 976610-001 Miter Table Frame 23 ** ST0851004 * Flat Washer (M4).................................. .................1
(Includes Key Nos. 10, 11, 12, & 13).....................1 24 976527-001 * Screw (M4 X 10 Pan Hd.).................... .................1
10 976531-001 Rivet.......................................... ............................ 3
25 976509-001 Miter Lock Plate.................................. .................1
11 976515-001 Miter Scale............................... ............................ 1 26 976568-001 Blade Wrench...................................... .................1
12 977434-001 Hand Warning Label................ ............................ 2 27 976570-001 5 mm Hex Key..................................... .................1
13 977435-001 Line Label................................. ............................ 2 28 976605-001 6 mm Hex Key...................................... .................1
14 976513-001 Table Spindle........................... ............................ 1 29 976569-001 8 mm Hex Key...................................... .................1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
