PARTS
CRAFTSMAN 2800 PSI Pressure Washer 580.752400
Main Unit — Exploded View and Parts List
KT
V
. 11
Item Part #
1
2
3
4
5
6
7
8
9
192393GS
E194719GS
194048GS
194548GS
192133GS
192131GS
B3263GS
B2203GS
192310GS
Description
BASE
HANDLE
ASSY, Billboard
HOSE
KIT, Engine Mounting Hardware
KIT, Pump Mounting Hardware
GUN
KIT, Handle Connector
KIT, Vibration Mount
item
10
11
12
13
14
15
16
17
900
Part#
192309GS
194264GS
191265GS
195303EGS
B1236EGS
192317GS
23139DGS
194059GS
NSP
-12
Description
KIT, Hook, Base
KIT, Hook, Handle
KIT, E-Ring
ASSY, Wand
ORIFICE
KIT, Wheel
KEY
ASSY, Pump (see page 23)
ENGINE
Items Not Illustrated
Part # Description
194052GS MANUAL. Owner’s
194263GS KIT, Decals
AB3061BGS OIL, Bottle
Optlonai Accessories
7175187GS
7175197GS
7175199GS
190249GS
7175116GS
7174400GS
B3635GS
7174402GS
7174403GS
7174300GS
7174301GS
7174302GS
7174303GS
7174307GS
Not Illustrated
Garden Hose Quick Connect
Accessory Quick Connect
Rotating Brush Kit
25' Replacement Hose
O Ring Repair Kit
Turbo Nozzle
25' Extension Hose
Hose Reel
Pump Saver
House Wash Concentrate (makes 4 gallons)
Deck Wash Concentrate (makes 2 gallons)
Vehicle/Boat Wash Concentrate (makes 4 gallons)
Degreaser Concentrate (makes 4 gallons)
Mold/Mildew Concentrate (makes 2 gallons)
