REPAIR PARTS FOR MODEL 486.248462 46" SNOW THROWER
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
1
63576
1
Housing Assembly
58
684-0061
1
Chute Crank Assembly
2
64517
1
Impeller Assembly
59
784-5149
1
U-Joint
3
47368
2
Spring Pin, 5/1
6" X
1-3/4"
60
43850
2
Roll Pin, 1/8"x5/8"
4
47369
2
Spring Pin, 3/16"
X
1-3/4"
61
43070
8
Flat Washer, 3/8"
5
63772
1
Spiral Assembly, R.H.
62
24300
1
Chute Crank Bracket, Rear
6
63771
1
Spiral Assembly, L.H. (Not Shown)
63
24299
1
Chute Crank Bracket, Front
7
018"040^5
1
Auger Gear Assembly
64
64504
1
Idler Arm Assembly
8
24308
1
Gear Housing Support Plate
65
24286
1
Pivot Spacer
9
784-5076
1
Gear Housing Support Bracket
66
63762
1
Idler Bracket Assembly
10
46703
1
Bolt, SelfThd., 5/16-18x3/4"
67
24472
1
Pivot Spacer
11
R19111116 7
Flat Washer, 11/32" x 11/16"
68
756-0405
2
Flat Pulley, 3-3/4"
12
43063
3
Hex Bolt, 5/16-18x1"
69
47044
1
V-ldler Pulley, 4"
13
43064
38
Hex Lock Nut, 5/16-18 Thd.
70
47064
1
V-Pulley, 5.9"
14
43086
30
Lockwasher, 5/16"
71
48102
1
V-Pulley, 10"
15
24913
1
Bearing Offset Bracket
72
738-0680
1
Shaft
16
48593
1
Spacer
73
750-0456
1
Spacer
17
47598
6
Flanged Lock Nut, 1/4-20 Thd.
74
750-0660
1
Spacer
18
24942
1
Belt Keeper Bracket
75
714-0161
2
Key
19
24941
1
Belt Cover
76
741-0919
2
Ball Bearing
20
47810
12
Nylock Nut, 5/16-18
77
08253B
1
Bearing Housing
21
47044
2
V-Pulley, Idler
78
15296A
1
Bearing Housing, Open
22
05845B
2
Bearing Housing
79
14088B
1
Spindle Spacer
23
24911
1
Idler Bracket, L.H.
80
44377
2
Hex Bolt, 3/8-24
X
1"
24
24910
1
Idler Bracket, R.H.
81
736-0247
2
Flat Washer, 3/8" x 1-1/4"
25
24912
1
Cross Tie Bracket
82
43063
3
Hex Bolt, 5/16-18x1"
26
48595
1
Key, 3/1
6" X
3/4"
83
43054
2
Hex Bolt, 3/8-16x2"
27
43353
2
Lockwasher, 1/2"
84
43432
2
Hex Bolt, 3/8-16x2-1/2"
28
43262
2
Hex Lock Nut, 1/2-13 Thd.
85
24571
1
Spacer
29
711-0242
2
Spacer
86
46963
2
Chain, Tensioning
30
44917
1
Palnut, 3/8"
87
43343
4
Hair Cotter Pin, 1 /8" #4
31
24309
1
Wear Plate
88
43055
2
Hair Cotter Pin, 3/32" #3
32
43080
20
Carriage Bolts, 5/16-18 x 3/4"
89
46959
2
Spring
33
43081
16
Fiat Washer, 5/16"
90
46961
1
V-Belt, Auger
34
24279
2
Skid Shoe
91
48569
1
V-Belt, Drive
35
G586868
2
Leveling Shoe
92
24295
1
Clutch & Pulley Frame
36
24481
2
Skid Shoe Bracket
93
731-0851A
3
Chute Keeper
37
43001
12
Hex Bolt, 3/8-16x1"
94
1643-60
1
Plastic Grip
38
43003
19
Lockwasher, 3/8"
95
24482
1
Anti-Rotation Bracket
39
43082
17
Hex Lock Nut, 3/8"
96
43661
6
Hex Bolt, 1/4-20
X
1"
40
44326
10
Carriage Bolt, 5/16-18 x 1"
97
43088
6
Flat Washer, 1 /4"
41
48570
1
Bearing, Self Aligning
98
43182
1
Hex Bolt, 5/16-18
X
3/4"
42
48572
1
Pulley, 9"
99
43083
2
Hex Nut, 5/16-18 Thd.
43
710-0696
1
Hex Bolt, 3/8-24 x 7/8"
100
48106
2
Shoulder Bolt, 3/8-16 x 5/8"
44
736-0247
1
Fiat Washer, 3/8" x 1-1/4"
101
43038
2
Pivot Lock Pin
45
731-1696
1
Discharge Chute Adapter
102
710-0891
2
Shear Bolt, 5/16-18x1-3/4"
46
784-5711
1
Chute Bracket, 6"
103
738-0492
1
Shaft, Spiral Axle
47
1543-69
5
Nylon Washer, 5/8"
104
714-0135
1
Woodruff Key, 1/4" x 3/4"
48 731-0903D
1
Lower Discharge Chute
105
741-0494
4
Flange Bushing
49 731-0846C
1
Upper Discharge Chute
106
736-0250
4
Flat Washer, 1"x 1-3/4"
51
731-1313C
1
Cable Guide
107
741-0192
2
Flange Bearing W/Flats
52
784-5594
1
Cable Bracket
108
46703
6
Bolt, Seif Thd. 5/16-18x3/4"
53
746-0928
1
Chute Control Cable
109
63572
1
Hanger Bracket Assembly, R.H.
54
746-0929
1
Chute Control Cable w/Clip
110
63571
1
Hanger Bracket Assembly, L.H.
55
43085
1
Hex Bolt, 5/16-18x1-1/2"
111
23924
1
Frame Bracket, R.H.
56
710-0896
1
Hex Screw, 1/4-14x5/8"
112
23923
1
Frame Bracket, L.H.
57
741-0475
2
Plastic Bushing, 3/8"
48568
1
Owner's Manual
