REF.
QTY.
DESCRIPTION
A
4
Hex Bolt, 1/4" X 1-3/4"
B
4
Hex Bolt, 1/4" X 2"
C
1
Hitch Pin
D
8
Nut, 1/4"
E
1
Hair Cotter Pin, 1/8"
1. Spreader Assembly
2. Control Cable
3. Hitch Tube, R.H. (Right Hand)
4. Hitch Tube, LH. (Left Hand)
5. Hitch Control Tube
6. Hitch Brackets (2)
TOOLS REQUIRED FOR ASSEMBLY
(2)7/16" Wrenches
REMOVAL OF PARTS FROM CARTON
• Remove a!i parts and hardware packages from the
carton. Lay out all parts and hardware and identify
using the itiustrations on page 3.
