Craftsman 917.272057 - Manual (Page 37)

TRACTOR - - MODEL NUMBER 917.272057
GROUND DRIVE
KEY
NO.
1
PART
NO.
DESCRIPTION
T ransaxle (See Breakdown)
KEY
NO.
64
PART
NO.
71170764
DESCRIPTION
Bolt, Hex 7/16-20 X 4 Grade 5
Peerless206-545C 65 STD551143 Washer
2 146682 Spring, Return, Brake 66 154778 Keeper, Belt, Engine, Fool Proof
3 123666X Pulley, Transaxle 70 134683 Guide, Mower Drive Belt, R.H.
4 12000028 Ring, Retainer 74 137057 Spacer, Axle
5 121520X Strap, Torque 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
6
17060512 Screw 5/16-18x3/4 76 STD581075 E-Ring
8 165866 Rod Shifter Fender STLT 77 123583X Key, Square 2.0 x .1845/1865
10 STD561210 Pin, Cotier 78 121748X Washer 25/32 x 1 -5/8 x 16 Ga
11 105701X Washer, Shift Plate 79 STD580025 Key Woodruff
13 74550412 Bolt 1/4-28 UNF W/Patch Gr. 8 80 145090 Arm, Shift
14 10040400 Washer Lock Hvy Helical 81 165592 Shaft Asm Cross Tapered 650 20
16 STD541431 Nut Lock Hx W/lns 5/16-18 x Gr.5 82 165711 Spring, Torsion
16 STD523710 Bolt Fin Hex 3/8-16UNC x 1 Gr. 5 83 19171216 Washer 17/32 x 3/4 x 16 Ga.
19 STD541437 Nut 84 166231 Link Transaxle
21 106933X Knob 85 150360 Nut, Nylock
22 130804 Rod, Brake 89 158391X428 Console, Shift, STLT
24 STD541237 Nut 90 124346X Nut, Self-Thding, Wsh Hd 1/4
25 106888X Spring, Brake Rod 96 STD624003 Retainer Spring 1"
26 STD551037 Washer 112 19091210 Washer 9/32 x 3/4 x 10 Ga.
27 STD561210 Pin 113 127285X Strap Torque 90 Degrees
28 175765 Rod, Parking Brake 116 72140608 Bolt Rdhd Sqneck 3/8-16 x 1.00
29 71673 Cap, Parking Brake 120 73900600 Nut Lock Fig. 3/8-16 Unc
30 169592 Bracket, Transaxle 145 74490540 Bolt, Hex FIghd 5/16-18 Gr. 5
32 STD523107 Bolt 150 175456 Spacer Retainer
34 175578 Shaft Assembly, Foot Pedal 151 19133210 Washer 13/32 x 2 x lOGa.
35 120183X Bearing, Nylon 156 166002 Washer Srrted 5/16ID x 1.125
36 STD551062 Washer 158 165589 Bracket Shift Mount
37 STD571810 Roll Pin 159 165494 Hub Tapered Flange Shift Lt
38 179114 Pulley, Idler 161 72140406 Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr.5
39 74760648 Bolt 162 73680400 Nut Crownlock 1/4-20 Unc
41 175556 Keeper, Belt, Idler 163 74780416 Bolt Hex Fin 1/4-20Unc x 1 Gr 5
47 127783 Pulley, Idler, V-Groove, Plastic 164 19091010 Washer 5/8 X .281 x lOGa
48 154407- Bellcrank Clutch Grnd Drv StI 165 165623 Bracket Pivot Lever
49 123205X Retainer, Belt 166 166880 Screw 5/16-18x5/8
50 STD523715 Bolt 168 165492 BoltShoulder5/16-18x.561
51 STD541437 Nut Crown Lock 3/8-16 UNC 169 165580 Plate Fastening Lt
52 STD541431 Nut Crown Lock 5/16-18 UNC 170 173894 Keeper Belt Transaxle
53 10571 OX Link, Clutch 197 169613 Nyliner Snap-In 5/8 ID
55 105709X Spring, Clutch Return 198 169593 Washer Nyliner 7/8 ID x .105 Hd
56 STD523712 Bolt Fin Hex 3/8-16 x 1-1/4 202 72110614 Bolt Carr. SH 3/8-16 x 1-3/4 Gr. 5
57 130801 V-Belt, Ground Drive 212 145212 Nut Flange Lock
59 169691 Keeper, Belt, Center Span
61
62 17120614
8883R
Screw 3/8-16 X. 875
Cover, Pedal
NOTE: All component dimensions given in U. S. inches
1 inch = 25.4 mm
63 175410 Pulley, Engine
