ENGINE PARTS
CRAFTSMAN 2400 PSl HIGH PRESSURE WASHER 919.679180
BRIGGS ENGINE MODEL #12F302-2017
28
o
2
27
Sw
45
4o
34
40.5CN
36,
REF.
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
25
499429 Piston Assembly
26
499425
Ring Set
28
499423 Piston Pin
(Standard)
(Standard)
29
499424 Connecting Rod
(Standard)
32
94699 Screw
(Connecting Rod)
33
262651
Exhaust Valve
27
263190
Piston Pin Lock
34
262652 Intake Valve
(Used After Code Date
35
691270 Valve Spring
97011200).
(Intake)
36
691270 Valve Spring
(Exhaust)
40
93312 Valve Retainer
45
262204 Valve Tappet
Included in Gasket Set-See Ref. No. 358.
Included 'n Carburetor Kit-See Ref. No. 121
♦ Included m Carburetor Gasket Set-See Ref. 977
0 Included in Valve Overhaul Gasket Set-See Ref. No
1095
