UNASSEMBLED PARTS

steering Wheel

Steenng

Wheel

Insert

Steenng Sleeve

Seat

(1) Knob

(1) Washer

17/32 X 1-3/16 X 12

Gauge

Mower

(5) Retainer Springs

(double loop)

(l)Front Plate

(2)Flanged

Pins

(2) Retainer Spnngs (single loop)

■

(4) Shoulder Bolt

(4) Retainer Springs

(double loop)

(4) Adjusting Bar

@ i

/'/

(4) Washers

(/

3/8x3/4x14Ga.

O

(4) Clevis Pins

I

(4) Wheels

(4) Locknut 3/8-16

(2) Locknuts 5/16-18

(2) Hex Bolts 5/16-18x1

Nose Roller

Nose Roller
Brackets

@

(2) Washers

17/32

X

7/8

X

16 Ga.

Key

Slope Sheet

(2) Keys

Video

Cassette

(1) Oil Drain Tube
For Future Use
