Sony KV-27TS29 User Manual
Trinitm qhr tv, Operating instructions, Owner’s record
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
3-756-618-24 (1)
Owner’s Record
The model and serial numbers are located at the rear of
the TV. Record these numbers in the spaces provided
below. Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No._
. Serial No..
Contents
Preface
This section tells you about special features,
safety information, and preparatory
information for using this manual.
Chapter 1: Setting Up
This section shows you the steps
necessary for installing and presetting for
TV, and how to connect optional video and
audio equipment.
Chapter 2: Using Basic Features
This section gives you basic information
about operating and adjusting your TV.
Chapter 3: Using Advanced
Features
This section shows you how to use Picture-
in-Picture, pre-programmed Remote
Commander and other useful features.
Trinitm Qhr TV
Operating Instructions
Before operating your TV, please read this manual
thoroughly and retain it for future reference.
KV-27TS29
KV-27TS32
KV-27TS36
KV-32TS36
KV-32TS46
KV-27TW77
KV-27TW78
KV-32TW67
KV-32TW68
KV-32TW77
KV-32TW78
KV-2970M
KV-2975M
Appendix
This section gives you specifications and
troubleshooting information.
For a detailed table of contents, see
page 3.
© 1995 by Sony Corporation
