15 3311857
SA18/24/30SHK Series Vented Gas Logs - Remote Hearth Kit (Continued)
Ref. Description 18” 24” 30”
13. Gas Supply Fitting 3304145 3304145 3304145
14. Flexible Gas Connector 3304176 3304176 3304176
15. Pilot Bracket 4303232 4303232 4303232
16a. Natural Gas Pilot Assembly 20000540 20000540 20000540
16b. Propane Gas Pilot Assembly 20000971 20000971 20000971
17. Pilot Mounting Screws 3309075 3309075 3309075
18a. Control Valve - NG 20000965 20000965 20000965
18b. Gas Valve - Propane 20000966 20000966 20000966
19. On/Off/RS Switch 7522355 7522355 7522355
20. Gas Supply Tube 20001240 20001240 20001240
21a. Brass Elbow/Orifice Holder - NG 3304006 3304006 3304006
21b. Brass Elbow/Orifice Holder - Propane 3304146 3304146 3304146
22. Short Stem Orifice for Natural Gas 20001574 (#23) 20000961 (#15) 20000961 (#15)
23. Brass Air Mixer/Orifice Holder 20000012 20000012 20000012
24. Long Stem Orifice for Propane Gas 20001281 (#49) 20007346 (#46) 20001279 (#41)
Log Set Replacement Parts
Ref. Description Log Sets
1. 18” Standard Round Log Set 20007854
1a. 24”/30” Round Right Front 20007833
1b. 18” Round Left Front 20007835
1c. 24”/30” Round Front Cross Log 20007834
1d. 18”/24”/30” Cross Log 20007837
1e. 18” Cross Log 20007836
1f. Top Log 20008335
2. 24” Standard Round Log Set 20007855
2a. 24”/30” Round Left Front 20007839
2b. 24”/30” Round Right Front 20007838
2c. 24”/30” Back Log 20007841
2d. 18”/24”/30” Cross Log 20007705
2e. 24”/30” Round Front Cross Log 20007704
2f. 24”/30” Cross Log 20007840
2g. Top Log (2 per set) 20008335
3. 30” Standard Round Log Set 20007856
3a. 24”/30” Round Left Front 20007839
3b. 24”/30” Round Right Front 20007842
3c. 30” Middle Front Log 20007706
3d. 24”/30” Back Log 20007841
3e. 18”/24”/30” Cross Log 20007705
3f. 24”/30” Round Front Cross Log 20007704
3h. Top Log 20008335
4. 18” Standard Split Log Set 20007857
4a. 18”/24”/30” Back Log 20007820
4b. 18”/24”/30” Cross Log 20007699
4c. 18” Split Right Front 20007823
4d. 18” Split Left Front 20007825
4e. Top Log #3 (2 per set) 20008337
4f. Top Log 20008336
5. 24” Standard Split Log Set 20007858
5a. 18”/24”/30” Back Log 20007820
5b. 18”/24”/30” Cross Log 20007699
