[T] LINE A, LINE B connectors
Two groups (A and B) of line input connectors for the
composite video and audio signals and their loop-through
output connectors.
To monitor the input signal fed through these connectors,
press the A or B input select button on the front panel.
VIDEO IN (BNC type): Connect to the video output of a
video equipment, such as a VCR or a color video
camera. For a loop-through connection, connect to the
video output of another monitor.
VIDEO OUT (BNC type): Loop-through output of the
VIDEO IN connector. Connect to the video input for a
VCR or another monitor.
When the cable is connected to this connector, the
75-ohms termination of the input is automatically
released, and the signal input to the VIDEO IN
connector is output from this connector.
AUDIO IN (phono jack): Connect to the audio output of a
VCR or to a microphone via a suitable microphone
amplifier. For a loop-through connection, connect to
the audio output of another monitor.
AUDIO OUT (phono jack): Loop-through output of the
AUDIO IN jack. Connect to the audio input of a VCR or
another monitor.
|T]Y/C-INPUT connectors (4-pin)
VIDEO: Connect to the Y/C separate output of a video
camera or a VCR.
AUDIO: Connect to the audio output of a video camera or
a VCR.
To monitor the input signal fed through these connectors,
press the Y/CA/TR button on the front panel.
jTjVTR input connectors (8-pin)
Line input for the video and audio signals. When
connected to the 8-pin TV connector of a VCR, the video
and audio playback signal from the VCR can be
connected with a single cable.
To monitor the input signal fed through this,connector,
press the Y/CATTR button on the front panel, with the
Y/C-INPUT connectors connected to no outputs.
When both VTR and Y/C-INPUT connectors are connected
to video equipment, the input signal fed through the
Y/C-INPUT connectors has priority over the one fed
through the VTR connectors.
[T]COLOR TEMP (temperature) selector
Select the color temperature position, 9300°K or 6500°K.
[TjCOMPO (component)/RGB selector
Set to COMPO to monitor component signal fed through
the R/R-Y, G/Y, B/B-Y connectors.
Set to RGB to monitor analog R/G/B signal fed through
the R/R-Y, G/Y, B/B-Y connectors.
[6]V HOLD (vertical hold) control
Turn to stabilize the picture if it rolls vertically.
[T] EXT SYNC (external sync) connectors (BNC type)
IN: Connect to the output of a sync generator.
To monitor the sync signal fed through this connector,
depress the EXT SYNC button.
OUT: Loop-through output of the SYNC IN connector.
Connect to the SYNC input of a video camera.
When the cable is connected to this monitor, the
75-ohms termination of the input is released, and the
signal input to the IN connector is output from this
connector.
[UCTRL S (control S) connectors (minijack)
For remote control of the APERTURE, BRIGHT,
CHROMA, PHASE, CONTRAST and VOL control buttons.
IN: Connect to the “control S” output of other equipment.
OUT: Connect to the CTRL S IN connector of another
monitor by using a connecting cord (miniplug-^
miniplug).
[9] ANALOG RGB/COMPONENT connectors (BNC type)
R/R-Y IN, GIY IN, B/B-Y IN:
To monitor the analog R/G/B signal, connect to the
analog R/G/B signal outputs of a video camera having no
sync signal.
Set the COMPO/RGB selector on the rear panel to RGB
and press the ANALOG RGB/COMPONENT button on
the front panel. When the EXT SYNC button is released,
the monitor operates on the sync signal from the G
channel.
To monitor the component signal, connect to the
R-Y/Y/B-Y component signal outputs of a Sony BetaCam
video camera. Set the COMPO/RGB selector on the rear
panel to COMPO and press the ANALOG RGB/
COMPONENT button on the front panel. When the EXT
SYNC button is released, the monitor operates on the
sync signal from the Y channel.
R/R-Y OUT, G/Y OUT, B/B-Y OUT:
Loop-through outputs of the R/R-Y IN, G/Y IN, B/B-Y IN
connectors.
For R/G/B signal, connect to the analog R/G/B signal
inputs of a video camera.
For component signal, connect to the R-Y/Y/B-Y
component signal inputs of a BETACAM video camera.
When the cables are connected to these connectors, the
75-ohms termination of the input is automatically
released, and the signal inputs to the R/R-Y IN, G/Y IN,
B/B-Y IN connectors are output from these connectors.
AUDIO IN: Connect to the audio output of video
equipment when the analog R/G/B or component
signal is input.
