Additional Information
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION
With 8-ohm load, both
channels driven, from 20 -
20,000 Hz, rated 100 watts
per channel, minimum RMS
power, with no more than
0.09% total harmonic
distortion from 250
milliwatts to rated output
(USA model only).
Amplifier section
POWER OUTPUT
Stereo mode
(8 ohms 20 Hz - 20 kHz,
THD 0.09%)
100 W -HOO W
Surround mode (8 ohms at 1 kHz, THD
0 . 8 % )
Front: lOOW/ch
Center*: lOOW '
Rear*: lOOW/ch
* Depending on the sound
field settings and the
source, sound will not be
output.
5.1/DVD mode (unavailable on STR-DE91S)
(8 ohms at 1 kHz, THD
0 . 8 % )
Front: lOOW/ch
Center: lOOW
Rear: lOOW/ch
Dynamic power output
155 W +155 W, 8 ohms
220W-t-220W,4ohms
Harmonic distortion at rated output
Less than 0.09% (with
DIRECT PASS on)
Frequency response
PHONO: RIAA
equalization curve
±0.5 dB
CD,TAPE,DAT/MD,
VIDEO 1,2,:
10 Hz - 50 kHz T dB (with
DIRECT PASS on)
Inputs
Sensitivity impedante
S/N
(weighting
network,
input level)
PHONO 2.5 mV
50
kilohms
75 dB*
(A, 2.5 mV)
CD (STR-
DE91S) 150 mV
CD (other
models) 200 mV
50 82 dB*
TAPE, DAT/MD,
VIDEO 1,
2, 3
(STR-OE915 ,,
only). 150 mV
LD/DVD,
TV/DBS
kilohms (A, 150 mV)
LD/DVD
AC-3 RF
(STR-DE91S
only)
- 75 n
100 dB
(A, 20 kHz,
LPF)
LD/DVD, CD,
OAT/MD
OPTICAL
(STR-0E91S
only)
- -
100 dB
(A, 20 kHz,
LPF)
5.1 INPUT
(Unavailable
on STR-
DE91S)
200 mV
50
kilohms
82 dB*
(A, 150 mV)
Surround
*V8IHF
Outputs VIDEO 1,2 AUDIO OUT:
Voltage: 150 mV,
Impedance: 10 kilohms
WOOFER:
Voltage; 2 V
Impedance: 1 kilohms
PHONES:
Accepts low and high
- impedance headphones
BASS BOOST STR-DE915: -^6dBat50Hz
STR-DE715/DE615/D660Z/
D560Z: -HO dB at 70 Hz
TONE (unavailable on STR-DE915)
±8 dB at 100 Hz and 10 kHz
Digital signal processor section
(STR-DE915only)
Modulation (A/D conversion)
High Density Linear
Converter
Demodulation (D/A conversion)
High Density Linear
Converter (Advanced
pulse D/A converter)
Sampling frequency
48 kHz
LFEMDC:
MUTE, -20 - 0 dB, 0.5 dB
step
D. RANGE COMP:
OFF, 0.1 - 0.9, STD, MAX
REAR level:
-20 - -i-lO dB, 0.5 dB step
CENTER level:
-20 - +10 dB, 0.5 dB step
SUB WOOFER level:
-20 - +10 dB, 0.5 dB step
EFFECT:
21-step adjustable
WALL:
17-step adjustable
SEATF/R:
17-step adjustable
SEATL/R:
17-step adjustable
REVERB time:
17-step adjustable
Depending on the sound
field, some parameters
may not be adjustable (see
page 26).
BAND: BASS/TREBLE
Turnover frequency:
Bass: 99 Hz-992 Hz
Treble: 1.0 kHz - 8.6 kHz
Level: ±10 dB, 0.5 dB step
FM tuner section
Tuning range 87.5 -108.0 MHz
Antenna terminals
75 ohms, unbalanced
Sensitivity Mono: 18.3 dBf, 4.5 ftV
Stereo: 38.3 dBf, 45 fiV
Usable sensitivity
11.2 dBf,2^V (IHF)
Equalizer
S/N Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response
, , ^ 30Hz-15kHz.t^dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range With 10 kHz interval;
530 -1710 kHz (USA and
Canadian model only**)
530 -1610 kHz (models for
all other countries except
for Australia)
With 9 kHz interval:
531 -1710 kHz (USA and
Canadian model only)
531 - 1602 kHz (Australian
model and models for all
other countries**)
